2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher

Certification
China Shenzhen Bitvisus Technology Limited certification
I'm Online Chat Now

2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher

2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher
2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher
2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher

Large Image :  2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher

Product Details:
Place of Origin: China
Brand Name: Bitvisus
Certification: CE,HDMI,HDCP,RoHS,FCC
Model Number: BIT-MSE-4K60-103PRO
Payment & Shipping Terms:
Minimum Order Quantity: 1Piece
Price: Contact Us
Packaging Details: Packing box
Delivery Time: 7-30day
Payment Terms: T/T, PayPal
Supply Ability: 1000Piece/30day

2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher

Description
Place Of Origin: Guangdong, China Model Number: BIT-MSE-4K60-103PRO
Brand Name: Bitvisus Output Max Resolution: 7680*1200@30Hz
Product Name: Hdmi Video Wall Controller Input Interfaces: HDMI Interface (priority)
Output Interfaces: HDMI Interface (optional) Input Type: HD: DP/DVI SP: HDMI/DP
Power Supply: 12V@2A AC-DC Power Supply EDID Modification: Supports EDID Modification Through USB Interface
Highlight:

2K Multi Display Controller

,

Multi Display Controller 2x2

,

HBT HDMI Display Switcher

Bitvisus 2K 4K 8K 2x2 2x3 3x3 1x3 1x4 2x1 HDMI Multi Screen Display Splicing Processor Switcher HBT Video Wall Controlle



Introducing the MSE-HBT-4K60-103PRO, an industrial-grade pinnacle of technology crafted to conquer the challenges of advanced multi-channel projection fusion. This robust video wall controller stands apart by harmoniously unifying an array of premium input interfaces, encompassing DP, DVI, and HDMI/DP, thereby assuring compatibility with an expansive portfolio of audio-visual devices.

Powered by the groundbreaking HBT standard output ports, the MSE-HBT-4K60-103PRO transcends traditional boundaries, ensuring seamless, high-bandwidth transmission and extension of your video signals. Each pixel is meticulously crafted to retain its pristine quality, even across vast distances, ensuring unparalleled visual clarity and immersion.





2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 0





Product Characteristics



1,Industrial-Grade Performance: Specifically developed for multichannel projection fusion, the MSE-HBT-4K60-103PRO boasts industrial-grade robustness and performance. It supports DP, DVI, or HDMI/DP input interfaces and HDBaseT standard output ports, ensuring seamless integration with your existing equipment.
2,Ultra-High Resolution Support: Enjoy stunning visuals with support for resolutions up to 2x3840x2160@30Hz, 3840x2160x2@30Hz, and 5760x1200@60Hz. Compatible with lower resolutions, it's the perfect solution for demanding applications.
3,EDID Modification via USB: Conveniently modify EDID settings through the built-in USB interface, simplifying setup and configuration processes.
4,High-End FPGA Chip: Equipped with a 45nm high-end programmable FPGA chip, the MSE-HBT-4K60-103PRO delivers full hardware real-time processing with lightning-fast speeds and zero delay.
5,Industrial Design & Durability: Boasting a thickened 6-layer PCB and 16KV anti-static protection, this video wall controller is designed for unmatched stability and longevity.
6,Parallel Operation Capability: Meet the real-time display demands of large screens with support for parallel operation, ensuring seamless video playback and synchronization across multiple screens.
7,Low Power & High Reliability: Engineered for low power consumption, the MSE-HBT-4K60-103PRO adopts internal conduction heat dissipation, eliminating the need for external cooling measures and enhancing overall reliability.





2K 4K 8K Multi Display Controller 2x2 2x3 3x3 1x3 1x4 2x1 HBT HDMI Display Switcher 1



Application Scenario

Ideal for a myriad of applications, including high-resolution desktop setups, large screen walls, command and dispatching systems, multi-screen video monitoring, engineering display solutions, multi-channel projection, virtual reality experiences, ring theaters, large advertising walls, and LCD/LED multi-screen configurations. The MSE-HBT-4K60-103PRO is your go-to solution for creating immersive and seamless visual experiences across various industries.



Specifications



Product name BIT-MSE-4K60-103Pro
Maximum video pixel frequency of input interface 600MHz
Maximum video pixel frequency of output interface 300MHz

BIT-MSE-4K60-103Pro

Highest resolution

2x3840x2160@30Hz,3840x2160x2@30Hz

3x1920X1200@60Hz; 3x1920X1080@60Hz

Default resolution: 3072x768@60Hz

Input interface type

HDMI interface, DP interface (choose one from two, HDMI priority)

Supports HDCP2.2

Out interface type

HDMI interface, DP interface (choose one from two, HDMI priority)

Supports HDCP2.2

Output line length 15 meter copper wire
Power Supply 12V@2A AC-DC Power Supply
Quality assurance One year
