Product Details:
|
| Model Number: | BIT-Ex-HBT-70 | Brand Name: | Bitvisus |
|---|---|---|---|
| Private Moldv: | Yes | Place Of Origin: | Guangdong, China |
| Product Name: | HBT HDMI Extender Video Transmission Equipment | Transmitter: | 70~130 |
| Type: | HDMI1.4 / HDMI1.2 | Power Supply: | DC 12V |
| HDMI Version: | HDMI1.4 | Certification: | FCC |
| Highlight: | 4K POE HDMI Extender,POE HDMI Extender 70M,4K HDMI Transmitter And Receiver |
||
An advanced HDMI 1.4 HD video signal extender, the BIT-Ex-HDBT-70, is designed to seamlessly transmit signals over various network cables, effectively extending transmission distances beyond the typical 230-feet limit of traditional Ethernet. Boasting support for 4Kx2K @ 30Hz resolution with backwards compatibility for lower resolutions, it ensures unparalleled visual clarity. For 4Kx2K @ 30Hz HDMI signals, it utilizes Cat.5e or Cat.6 cables with a maximum reach of up to 130 feet, leveraging the HDBaseT standard for reliable, uncompressed video transmission. This extender, with its low-power fanless design and POE capability, simplifies installation and reduces maintenance costs, making it ideal for multi-screen setups, projection fusion projects, and other AV applications that demand extended signal reach.
| BIT-E x-HDBT-70 | ||
| import | transmitting terminal (TX) | HDMI 1.4 (5m), IR, RS232 signal |
| receiving terminal (RX) | CAT 6E,70m | |
| output | transmitting terminal (TX) | CAT 6E,70m |
| receiving terminal (RX) | HDMI 1.4 (5m), IR, RS232 signal | |
| audio frequency | HDMI, the audio comes out with you | |
| other | Support resolution |
4K30H z downward compatibility; 7680x1200@30,5760X1200@30,7680X1080@30 |
| signal format | Support common resolution in various input signal formats; support common signal formats for VESA and HDTV | |
| Color space | Support for RGB444; YUV color space | |
| Pixel bandwidth | 165 MHz / 300 MHz, full number | |
| Transmission bandwidth | 10.2G bps | |
| transmission distance |
1080p resolution CAT 6,70m 4k 30 resolution CAT 6 E, 40m |
|
| CEC | support | |
| RS232/IR | bidirectional RS232 transmission / bidirectional IR | |
| 3D | support | |
| POE supply electricity | One-way power supply | |
| Interface protocol | HDMI 1.4, HDCP 2.2 is compatible with DVI 1.0, VGA | |
|
EDID Solid transmission / through transmission |
support | |
| OEM | support | |
| source | DC 12V 2A | |
| power dissipation | ≤12W | |
| Storage / operating temperature | -10～50ºC/-25～55ºC | |
| use | The HDMI, KVM, IR, and RS232 signal was prolonged | |
| specifications | size | 105*76*27mm |
| weight | About 0.5KG | |
| packing list | Equipment * 2, power supply * 1, certificate * 1, warranty card * 1 | |
| after-sale service | The warranty is 1 year | |
