Product Details:
|
| Model Number: | BIT-MV-4K60-401 | Brand Name: | Bitvisus |
|---|---|---|---|
| Package Contents: | Power Cable, HDMI Cable, Remote Controls, Device | Private Mold: | Yes |
| Input Connector Type: | 4 HDMI Inputs | Output Interface Type: | 1 HDMI Output |
| Factory Default Resolution: | 1920x1080@60Hz | Power Supply: | 12V@2A AC-DC Power Supply |
| Color: | Black | Size: | Length, Width, Height (233mm*108mm*28.7mm) |
| Highlight: | High Definition HDMI Multi Viewer,HDMI Multi Viewer 4K60 |
||
Optimized Content:
The BIT-MV-4K60-401 stands as a pinnacle in high-performance image segmentation processing, equipped with a state-of-the-art high-definition processing chip. It seamlessly integrates 1080P signal input capabilities with versatile 4K60/1080P signal output, leveraging HDMI interfaces for both input and output.
Perfectly suited for a myriad of compact yet demanding projects, including playrooms, advanced multi-screen surgical theaters, cutting-edge studios, multimedia-driven gymnasiums, immersive game rooms, and beyond, the BIT-MV-4K60-401 ensures exceptional visual clarity and versatility.
Key Features:
4 HDMI Inputs:
Supports an input resolution of 1920x1080@60Hz, catering to the needs of Full HD content.
Boasts a maximum video pixel frequency of 165MHz, ensuring smooth and responsive video processing.
1 HDMI Output:
Delivers unparalleled visual experiences with support for both 1920x1080@60Hz and 3840x2160@60Hz resolutions, seamlessly transitioning between Full HD and stunning 4K Ultra HD.
Features an astonishing highest video pixel frequency of 594MHz, pushing the boundaries of image fidelity and clarity.
Offers an output distance of up to 10 meters, providing ample flexibility for installation and setup in various environments.
| Product Name | BIT-MV-4K60-401 |
| Input interface maximum video pixel frequency | 165MHz |
| Output interface maximum video pixel frequency | 594MHz |
| Input maximum resolution | 1920x1080@60Hz |
| Maximum output resolution | 3840x2160@60Hz |
| HDMI input interface | 4 x HDMI1.3 |
| HDMI output interface | 1 x HDMI2.0 |
| Control Mode | Remote Control, Button, RS232 |
| Factory default resolution | 1920x1080@60Hz |
| Input connector type | 4 HDMI inputs |
| Output interface type | 1 HDMI output |
| Size | Length, Width, Height (233mm*108mm*28.7mm) |
| Weight | 1.8KG |
| Power Supply | 12V@2A AC-DC power supply |
| Warranty | one year |
Product Features
1. The input supports HDMI 1.3, HDCP 1.4;
2. Supports single-screen rotation, left-right screen splitting, top-bottom screen splitting, four-screen splitting, equal-ratio splitting, one big and three small splits;
3. Pure hardware design, plug and play, no software required;
4. Support seamless switching and overall brightness adjustment;
5. Support button control, remote control, serial port control;
6. Support audio channel switching, audio separation;
7. Low power consumption, energy saving and environmental protection design, the internal use of conduction heat dissipation,
without any external heat dissipation measures, reliable sex is very high.
