Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher

Certification
China Shenzhen Bitvisus Technology Limited certification
I'm Online Chat Now

Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher

Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher
Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher
Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher

Large Image :  Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher

Product Details:
Place of Origin: China
Brand Name: Bitvisus
Certification: CE,HDMI,HDCP,RoHS,FCC
Model Number: BIT-MSE-209Pro
Payment & Shipping Terms:
Minimum Order Quantity: 1Piece
Price: Contact Us
Packaging Details: Packing box
Delivery Time: 7-30day
Payment Terms: Paypal, T/T,
Supply Ability: 1000Piece/30day

Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher

Description
Product Name: BIT-MSE-209Pro Input Interface: 2-way HDMI 2.0/DP 1.2(choose One Of Two)
HDCP Features: HDCP 2.2 Is Supported Resolution: 4Kx2K@60H
Input: 2 HDMI 2.0/DP 1.2 Output: 9 HDMI 1.3
Power Supply: DC 12V/2A Power Consumption: 22W
Products Size: 30*14.2*3.5cm Warranty: 3 Years
Highlight:

Multi Channel Video Wall Matrix Switcher

,

HDMI Video Wall Matrix Switcher

BIT-MSE-209Pro Industrial-Grade Multi-Desktop & Multi-Channel HDMI/DP Matrix Switcher


Introducing the BIT-MSE-209Pro, an unparalleled industrial-grade high-performance matrix switcher designed exclusively to streamline multi-desktop operations and multi-channel project management. This advanced solution effortlessly integrates HDMI/DP input interfaces with HDMI output interfaces, empowering users to create dynamic and efficient video configurations.


Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher 0



Key Features:



Versatile Connectivity:
Supports up to 2 inputs and 9 outputs, allowing for flexible combinations across 9 screens, catering to diverse display needs.
A single input channel boasts a maximum resolution of 3840x2400@60Hz, ensuring stunning visuals while maintaining backward compatibility with lower resolutions based on splicing modes.
Customizable Display:
Fixed EDID design enables tailored input resolution configurations, ensuring seamless integration with various source devices.
Supports multiple display modes including 1xN, Nx1, NxN, point-to-point, with no stretching, deformation, or compression for crystal-clear picture quality.
Ultra-Low Latency & Real-Time Processing:
Equipped with a premium 28mm process high-end programmable FPGA chip, delivering full hardware-based real-time processing architecture for ultra-fast speeds and zero delay.
Ideal for demanding applications requiring instantaneous response and precise timing.
Robust & Reliable:
Designed with superior anti-static protection, safeguarding the product against electrical surges and ensuring long-term durability.
Active air cooling heat dissipation system ensures stable operation across a wide range of temperatures, adapting to various environmental conditions.
Diverse Compatibility & Applications:
Compatible with computers, Android boxes, game consoles, and more, making it a versatile solution for diverse input sources.
Seamlessly integrates with various video extenders or splitters, expanding its reach into more complex scenarios, including digital signage, broadcast studios, control rooms, and gaming setups.



Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher 1Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher 2Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher 3Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher 4Industrial Multi Desktop Multi Channel HDMI / DP Video Wall Matrix Switcher 5



Product name BIT-MSE-209Pro
Input Input interface 2-way HDMI 2.0/DP 1.2(choose one of two)
HDCP features HDCP 2.2 is supported
Transmission distance ≤5 meters
Enter the highest pixel clock 600MHz
Input single-port resolution 3840x2160@60Hz/3840x2400@60Hz
5760x3240@30Hz/7680x2160@30Hz
(4Kx2K@60Hz Resolution within bandwidth)
Input color format RGB888,24bit
Output Output port 9-way HDMI 1.3
Transmission distance ≤15 meters
Output the highest pixel
clock
165M
Output single mouth

resolution
1920x1080@60Hz

1920x1200@60Hz
(customizable)
Output color format RGB888,24bit
Audio Audio output HDMI output,3.5mm audio port (audio
separation
Specifi

cations
Power supply DC 12V/2A
Maximum power
consumption
22W
Storage/working
temperature
-10 to 50°C/0 to 50°C
Product dimensions Length 300mm*width 142mm*height 35mm
Package weight (net weight
of equipment)
1.8 KG
List of accessories 12V/2A power supply *1,HDMI/DP cable *2,
certificate*1,warranty card*1
Others After sales service 3 years warranty
