20KM RS232 KVM EDID HDMI Fiber Extender With Audio Output 3840x2160@30Hz

Description
Brand Name: Bitvisus Model Number: BIT-Ex-Fib-IP-4K-KVM
Maximum Transmission DistanceDistance: 30 Kilometers Transmission Technology: Fiber Optic
Maximum Supported Resolution: 3840x2160@30Hz Video Processing Chip: Industry's Most Advanced
Video Interface: HDMI Backward Compatibility: Supports Lower Resolutions
Power Consumption: Low EDID Learning: Yes, Supports Reading Display EDID
Highlight:

EDID HDMI Fiber Extender

,

20KM HDMI Fiber Extender

,

RS232 HDMI Extender With Audio Output

Bitvisus 3840x2160@30Hz HDMI Audio Out 20Km RS232 KVM EDID Fiber HDMI Extender

The BIT-Ex-Fib-IP-4K-KVM is a cutting-edge UHD Fiber Video Extender, revolutionizing uncompressed, zero-latency multimedia transmission over fiber. It effortlessly carries video, audio, USB-KVM, and RS232 up to 30km (officially 10KM via HDMI 1.4), outperforming rivals.

Future-proofed, it supports 4K@30Hz with backwards compatibility. Its rugged industrial design ensures reliability in tough environments. Plug-and-play, it simplifies installation and avoids software drivers, making it a professional's choice.

Key differentiators: EDID compatibility, bi-directional RS232, and comprehensive USB-KVM for remote control and management. Perfect for retail, sports, exhibitions, theme parks, and conferences where precision and control are paramount.


20KM RS232 KVM EDID HDMI Fiber Extender With Audio Output 3840x2160@30Hz 0

 Product Features

Select the most advanced video processing chip in the industry, with
powerful functions, high picture restoration, long transmission distance
and low power consumption.

20KM RS232 KVM EDID HDMI Fiber Extender With Audio Output 3840x2160@30Hz 1

Application scenarios

It can be used in various scenes such as shopping malls, gymnasiums,
exhibition halls, theme parks, conference rooms, etc.


Product Specifications

BIT-Ex-Fib-IP-4K-KVM
Input Transmitter(TX) HDMI 1.4(≤5m),IR,RS232 signal
Receiver(RX) LC-LC single-mode single-core fiber,10KM
output Transmitter(TX) LC-LC single-mode single-core fiber,10KM
Receiver(RX) HDMI1.4(≤5m),IR,RS232 signal
audio HDMI audio out
other Supported resolution 4K30Hz is backward compatible with standard

resolutions
Signal format Support common resolutions under various input signal
formats ;support common signal formats of VESA and

HDTV
color space Support RGB444;YUV color space
Pixel bandwidth 297MHz
Transmission

bandwidth
1.25Gbps
Transmission

distance
10KM
through the switch Support one-to-one,one-to-many(up to 32)optional
(PS:All-gigabit smart switch,supports port MAC

address binding,each port requires 800MBPS of

bandwidth,and the port is not recommended to be full)
EDID learning support
KVM USB 2.0,keyboard and mouse,U disk,radar,infrared

touch,printer,etc.
  CEC support
RS232 Two-way RS232 transparent transmission
3D support
Remote wake up support
Interface Protocol HDMI1.4,HDCP1.4 compatible with DVI1.0,VGA
OEM support
power supply DC 12V 2A
Power consumption ≤6W
Storage/operating

temperature
-10~50℃/-25~55℃
use HDMI,KVM,RS232 signal extension
Specification size 105*76*27mm
weight About 0.5KG
packing list Equipment*2,power supply*2,double-ended USB

cable*1,single-mode single-core optical module *2,
certificate *1,warranty card*1
After-sales service I year warranty
