Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM

Certification
China Shenzhen Bitvisus Technology Limited certification
I'm Online Chat Now

Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM

Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM
Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM
Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM

Large Image :  Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM

Product Details:
Place of Origin: China
Brand Name: Bitvisus
Certification: CE,HDMI,HDCP,RoHS,FCC
Model Number: BIT-Ex-Fib-IP-4K-KVM
Payment & Shipping Terms:
Minimum Order Quantity: 1Piece
Price: Contact Us
Packaging Details: Packing box
Delivery Time: 7-30day
Payment Terms: T/T, PayPal
Supply Ability: 1000Piece/30day

Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM

Description
Place Of Origin: China Private Mold: Yes
Brand Name: Bitvisus Model Number: BIT-Ex-Fib-IP-4K-KVM
Product Name: Fiber Optic Extender Interface Protocol: HDMI1.4/HDCP1.4 Compatible With DVI 1.0/VGA
Resolution: 3840x2160@30Hz Audio: HDMI Audio Out
Power Consumption: Low EDID Learning: Yes, Supports Reading Display EDID
Highlight:

EDID HDMI Fiber Optic Extender

,

KVM HDMI Fiber Optic Extender

Bitvisus Zero Delay 3840x2160@30Hz 20Km RS232 KVM EDID HDMI Fiber Optic Extender

  • Experience unparalleled visual clarity with our advanced 4K30Hz Ultra-HD transmission solution, featuring industry-leading video processing, extensive 20km transmission range, flexible resolution support, bidirectional RS232 communication, USB-KVM convenience, intelligent EDID learning, zero-delay uncompressed transmission, and effortless plug-and-play installation. Consult us for tailored project requirements.

Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM 0
  •

    • Stunning Ultra-HD Visuals: Experience unparalleled clarity with 4K30Hz ultra-high-definition picture quality, powered by the industry's leading video processing chip. This ensures a smooth and power-efficient transmission, even over long distances.

    • Extensive Transmission Range: Push the boundaries with support for the longest transmission distance of up to 20 kilometers, utilizing HDMI interface for both input and output, making it ideal for vast installations and remote connections.

    • Flexible Resolution Support: Customize your viewing experience with support for resolutions up to 3840x2160@30Hz, while seamlessly backward compatible with lower resolutions, ensuring compatibility with a wide range of devices.

    • Bidirectional RS232 Communication: Enhance control capabilities with built-in bidirectional RS232 communication, allowing for seamless integration and remote management of connected devices.

    • USB-KVM Convenience: Boost productivity with the USB-KVM function, featuring dual USB ports for direct connection of mouse and keyboard, enabling seamless control and switching between multiple devices.

    • Intelligent EDID Learning: Simplify setup with EDID learning, automatically reading the monitor's EDID information for immediate compatibility and optimal display settings.

    • Zero-Delay Transmission: Experience lag-free, uncompressed long-distance transmission, ensuring seamless video and audio streaming without compromise on quality.

    • Effortless Installation & Operation: Designed for hassle-free deployment, our product boasts a plug-and-play setup process, making it easy to install and operate, even for non-technical users.


Zero Delay RS232 KVM EDID HDMI Fiber Optic Extender 20Km BIT-Ex-Fib-IP-4K-KVM 1

Application scenarios

It can be used in various scenes such as shopping malls, gymnasiums,
exhibition halls, theme parks, conference rooms, etc.


Product Specifications

BIT-Ex-Fib-IP-4K-KVM
Input Transmitter(TX) HDMI 1.4(≤5m),IR,RS232 signal
Receiver(RX) LC-LC single-mode single-core fiber,10KM
output Transmitter(TX) LC-LC single-mode single-core fiber,10KM
Receiver(RX) HDMI1.4(≤5m),IR,RS232 signal
audio HDMI audio out
other Supported resolution 4K30Hz is backward compatible with standard

resolutions
Signal format Support common resolutions under various input signal
formats ;support common signal formats of VESA and

HDTV
color space Support RGB444;YUV color space
Pixel bandwidth 297MHz
Transmission

bandwidth
1.25Gbps
Transmission

distance
10KM
through the switch Support one-to-one,one-to-many(up to 32)optional
(PS:All-gigabit smart switch,supports port MAC

address binding,each port requires 800MBPS of

bandwidth,and the port is not recommended to be full)
EDID learning support
KVM USB 2.0,keyboard and mouse,U disk,radar,infrared

touch,printer,etc.
  CEC support
RS232 Two-way RS232 transparent transmission
3D support
Remote wake up support
Interface Protocol HDMI1.4,HDCP1.4 compatible with DVI1.0,VGA
OEM support
power supply DC 12V 2A
Power consumption ≤6W
Storage/operating

temperature
-10~50℃/-25~55℃
use HDMI,KVM,RS232 signal extension
Specification size 105*76*27mm
weight About 0.5KG
packing list Equipment*2,power supply*2,double-ended USB

cable*1,single-mode single-core optical module *2,
certificate *1,warranty card*1
After-sales service I year warranty
