Product Details:
Place of Origin: China
Brand Name: Bitvisus
Certification: CE,HDMI,HDCP,RoHS,FCC
Model Number: BIT-MSE-U1-416
Payment & Shipping Terms:
Minimum Order Quantity: 1Piece
Price: Contact Us
Packaging Details: Packing box
Delivery Time: 7-30day
Payment Terms: T/T, PayPal
Supply Ability: 1000Piece/30day

Professional Video 4 Input 16 Outputs LED TV Splicing Screen 4x4 4x16 4K 8K HDMI Video Wall Controller

Description
Place Of Origin: Guangdong, China Model Number: BIT-MSE-U1-416
Brand Name: Bitvisus Feature: TV Wall Controller
Type: Digtal Input Max. Pixel FPS: 600MHz
Output Max. Pixel FPS: 165MHz Size: 482.6mm*396.8mm*44mm
Types Of Input Interface: 4 DP 4 HDMI 1 RJ45 Lan 1 RJ45 Debug Port Types Of Output Interface: 4~16 HDMI

Professional Video 4 Input 16 Outputs LED TV Splicing Screen 4x4 4x16 4K 8K HDMI Video Wall Controller​



The BIT-MSE-U1-416 is an industrial-grade, high-performance Ultra HD splicing processor designed for the most demanding applications. It supports ultra-high-definition resolutions up to 8Kx2K@60Hz, ensuring seamless visuals across multiple displays. This advanced unit combines power and flexibility, supporting up to 4 inputs and 16 outputs, enabling versatile splicing configurations and large-scale parallel use. With a 28nm high-end programmable FPGA chip, it processes signals in real-time without delay, providing users with an unparalleled visual experience.





Professional Video 4 Input 16 Outputs LED TV Splicing Screen 4x4 4x16 4K 8K HDMI Video Wall Controller 0



Key Features


Ultra-High Resolution: Supports resolutions up to 8Kx2K@60Hz for crisp, clear visuals.
Multi-Input & Multi-Output: Maximum 4 inputs and 16 outputs for diverse splicing modes and large-scale configurations.
Industrial-Grade Design: Features a thickened 6-layer PCB board, 16KV super anti-static ability, and exceptional stability.
Efficient Power Supply: Adopts wide voltage (100~240V) centralized power supply with low power consumption for energy-saving operation.
Network Control: Supports both wired and wireless network control for seamless integration into existing systems.
Customization: Can be customized to meet specific splicing needs, catering to diverse user requirements.
Fast Processing: Utilizes a 28nm high-end programmable FPGA chip for ultra-fast, real-time processing.



Product Parameters


Maximum Input Resolution: Supports various configurations including 7680x4320@60Hz (4x4), 3840x7560@60Hz (7x2), etc.
Output Interface: 4~16 HDMI ports for seamless connectivity to multiple displays.
Input Interface: 4 DP, 4 HDMI, 1 RJ45 LAN (for control), 1 RJ45 Debug port, supporting HDCP 2.2.
Size: 482.6mm x 396.8mm x 44mm
Weight: 5kg
Power Supply: 100~240V
Warranty: One year





Professional Video 4 Input 16 Outputs LED TV Splicing Screen 4x4 4x16 4K 8K HDMI Video Wall Controller 1



Application scenarios



Ultra-high resolution desktop applications, ultra-large screen
walls, command and dispatch systems, multi-screen video
surveillance, engineering display applications, multi-channel
projection, virtual reality, surround-screen theater, large
advertising walls, LCD/LED multi-screens, etc.



Specifications



Product name BIT-MSE-U1-416 Ultra HD splicing


processor
Input Max.Pixel FPS 600MHz
Output Max.Pixel FPS 165MHz
4x4 highest resolution 7680x4320@60Hz
7x2 highest resolution 3840x7560@60Hz
2x7 highest resolution 13440x2160@60Hz
3x5 highest resolution 9600x3240@30Hz
5x3 highest resolution 5760x5400@30Hz
2x5 highest resolution 9600x2160@60Hz
5x2 highest resolution 3840x5400@60Hz
16x1 highest resolution 30720x1080@60Hz
1x16 highest resolution 1920x17280@60Hz
1x5 highest resolution 9600x1080@60Hz
1x7 highest resolution 13440x1080@60Hz

Factory default

resolution
3840x2160@60Hz
Support customized

arbitrary resolution
Types of input interface 4 DP


4 HDMI


1 RJ45 Lan

1 RJ45 Debug port

HDCP2.2
Types of output interface 4~16 HDMI
Size 482.6mm*396.8mm*44mm
Weight 5kg
