Product Details:
|
| Brand Name: | Bitvisus | Place Of Origin: | Guangdong, China |
|---|---|---|---|
| Model Number: | BIT-MSE-4K60-104PRO | Frequency Range (Hz): | 30-60hz |
| Input Type: | HDMI Or DP | Dimension (L X W X H): | 36x23x9CM |
| Output Distance: | 15 Meters | Type: | 4k Video Wall Controller |
| Feature: | Maximum Resolution Of 7680x1200 | Warranty: | One Year |
| Highlight: | 4x7 HDMI Matrix Switcher,3x7 HDMI Matrix Switcher,3x5 8k Video Wall Processor |
||
Introducing an industrial-grade, high-performance marvel tailored exclusively for the intricate demands of multi-desktop operation and advanced multi-channel projection fusion. This revolutionary product stands apart with its utilization of HDMI input interface and DVI output, ensuring seamless integration and compatibility across a wide range of professional setups.
Designed to push the boundaries of what's possible in multi-display environments, it delivers unparalleled performance, flexibility, and reliability – perfect for mission-critical applications requiring unparalleled visual fidelity and real-time responsiveness.
Super high resolution, the output supports a maximum resolution of 7680x1200 @ 30Hz / 1920x4800 @ 30Hz, which is backward compatible with low resolution.
Support 1xN, Nx1, MxN and 90 ° rotation ratio stitching, without stretching, deformation, and wider field of vision.
Adopt high-end programmable FPGA chip with 45nm technology, full hardware real-time processing architecture, ultra fast processing speed without delay.
Industrial-grade design, thickened 6-layer PCB board, 16KV super strong anti-static ability, super product stability.
Support parallel operation to meet the real-time display requirements of large screen.
Low power consumption, energy saving and environmental protection design. Conductive heat dissipation is used inside without any external heat dissipation measures.
Common application includesUltra-high-resolution desktop applications, large screen walls, command and dispatch systems,multi-screen video surveillance, engineering display applications, multi-channel projection, VR, ring screen theaters, large advertising walls, LCD / LED multi-screen, etc.
| Product name | BIT-MSE-4K60-104PRO |
| Input Max. Pixel FPS | 600MHz |
| Output Max. Pixel FPS | 330MHz |
| Input type | HDMI or DP (choose one, HDMI priority) |
| Output type | 4 HDMI |
| 3 screens support typical resolution | 3x1920x1200@60Hz 3x1920x1080@60Hz 3x1280x800@60Hz 3x1024x768@60Hz |
| 4 screens support typical resolution | 4x1920x1200@60Hz 4x1920x1080@60Hz 4x1280x800@60Hz 4x1024x768@60Hz |
| Product factory default resolution | 3840x2160@60Hz |
| 2x2 Max supported resolution | 3840x2400@60Hz |
| 3x1/1x3Max supported resolution | 1920x3600@60Hz/5760x1200@60Hz |
| 4x1/1x4Max supported resolution | 1920x4800@60Hz/7680x1200@60Hz |
| Output distance | 15 meters |
| power supply | 12V@2A AC-DC |
| Warranty | One year |
