Splicing Screen HDMI Video Controller 1x4 4x1 8K Multi Screen Expansion

best selling display monitor splicing screen 1x4 4x1 HDMI video processor 8K Multi screen expansion

best selling display monitor splicing screen 1x4 4x1 HDMI video processor 8K Multi screen expansion specificities

Experience unparalleled visual clarity with our solution that flawlessly supports Row 1 Column N configurations, ensuring pixel-perfect replication with zero stretching or deformation, and a vastly expanded field of vision.

Leveraging cutting-edge 45nm process technology, our high-performance, programmable FPGA chip delivers a fully hardware-based real-time processing architecture, boasting ultra-fast speeds that push the boundaries of image processing.

Designed for rugged industrial environments, our solution boasts a robust 16Kv super anti-static capability and unparalleled high stability, ensuring seamless operation even in the most demanding conditions.

To cater to the real-time display demands of large screens, we've incorporated a parallel mode that effortlessly scales up performance, ensuring smooth and seamless visuals every time.

Embracing eco-friendly principles, our low-power consumption design promotes energy efficiency and environmental protection. With an internal conduction heat dissipation system that eliminates the need for external cooling measures, our solution offers unparalleled reliability and longevity.

best selling display monitor splicing screen 1x4 4x1 HDMI video processor 8K Multi screen expansion appliance

Ultra high resolution desktop application, super large screen wall, command and dispatching system, multi screen video monitoring, engineering display application, multi-channel projection, virtual reality, ring screen cinema, large advertising wall, LCD / LED multi screen, etc.

best selling display monitor splicing screen 1x4 4x1 HDMI video processor 8K Multi screen expansion Specification

Parameters	BIT-MSE-8K-204HD
Single input maximum resolution	600MHz
Single output maximum resolution	165MHz
Input port	2 * DP HDCP2.2
Output port	4 *HDMI
2 screens splicing mode	2x1920x1200@60Hz 2x1920x1080@60Hz 2x1024x768@60Hz 2x1280x720@60Hz 2x3840x2160@30Hz
Default	3840x1200@60Hz
Row 1 Column 2 splicing mode	7680x2160@30Hz
Row 2 Column 2 splicing mode	7680x4320@30Hz
Output distance (Normal HDMI cable)	15 meters
Power	12V@2A AC-DC
Warranty	1 Year
Size	186mmx204mmx29mm





FAQ

Bitvisus FAQ

Why Choose Bitvisus ?

1.We have our own warehouse, which can ensure us of shipping out orders within 48 hours after payment(weekends and holidays excluded).

2. OEM/ODM offered for our customers.

3.We are one of leading Manufacturer in this field.

How to order ?

1. Pls send email or chat with us via TM, WHATS UP, SKYPE, and let us know your Requirements on order details.
2.We will reply you with proforma invoice based on your order request.

3.Kindly check the PI, and if everything is ok, the goods will be delivered to you asap after we got your payment.
Warranty & After-sale

1.Our products come with 12 months warranty and life-time service support.

2.You can return or exchange your items in any of the following Circumstances; Faulty items, Damaged items or wrong models.

Shipment & payment

1.T/T, Visa, PayPal, Western Union, L/C available.
2.DHL, UPS, EMS, FedEx, Air freight, Sea freight supported.
