Multi-Screen Expander Video Wall Controller with HDMI/DP Input Bitvisus Edge Fusion Blending and Immersive Interaction
Bitvisus UHD WUXGA projection mapping edge fusion blending immersive interaction multi-screen expander video wall controller MSE-HBT-4K60-104PRO is an an industrial grade high-performance product specially developed for the demand of multichannel projection fusion. It adopts DP, DVI or HDMI / DP ...
Multi-Screen Expander Video Wall Controller
,Edge Fusion Blending Video Wall Controller
,Immersive Interaction Video Wall Controller
Bitvisus UHD WUXGA projection mapping edge fusion blending immersive interaction multi-screen expander video wall controller
MSE-HBT-4K60-104PRO is an an industrial grade high-performance product specially developed for the demand of multichannel projection fusion. It adopts DP, DVI or HDMI / DP input interface, HBT standard output port, and supports chassis.
Specification
| Product Name | BIT-MSE-HBT-4K60-104PRO |
| Maximum video pixel frequency of input interface | 600MHz |
| Maximum video pixel frequency of output interface | 330MHz |
| Highest Resolution | 4x1920X1200@60Hz; 4x1920X1080@60Hz Default resolution: 3840x2160@60Hz |
| Input interface type | 1x DP/1x DVI/1x HDMI 1xDP+1xDVI or 1xDP+1xHDMI (optional) |
| Out interface type | 4 standard HBT port outputs |
| Transmission distance | 70m, 100m optional |
| Power Supply | 12V@2A AC-DC Power Supply |
Bitvisus UHD WUXGA projection mapping edge fusion blending immersive interaction multi-screen expander video wall controller
●Higher resolution support 7680x1200@30Hz,compatible with low resolution.
●45nm high-end programmable FPGA chip, which is full hardware real-time processing architecture and extremely fast processing speed without delay.
●Industrial design with thickened 6-layer PCB and 16KV anti-static , strong product stability.
●Support parallel operation to meet the real-time display demand of large screen.
●Low power design, the internal adopts conduction heat dissipation without any external heat dissipation measures, so the reliability is very high.
