Highlight:
Seamless UHD Video Switch
, Matrix 4x4 video wall controller
, 4k Hdmi Matrix Video Wall Controller
3x1 2x1 2x2 Support 4 Screen Division Seamless UHD Video Switch 4k Hdmi Matrix 4x4 video wall controller
High-Resolution Capabilities: Features a 4-way HDMI 2.0 interface supporting up to 4096x2160@60 resolution, with backward compatibility.
Advanced Splicing Features: Supports point-to-point splicing matrix, splicing overlay, and seamless switching between two curtains. Offers any split roaming overlay for versatile display configurations.
Audio-Video Separation:
Inputs: Accepts audio from both 4-way HDMI and 3.5mm (TRS) interfaces.
Outputs: Provides audio through 4-way HDMI, 4-way 3.5mm (TRS), and 4-way S/PDIF interfaces, with S/PDIF dedicated for audio processing.
Versatile Control Options: Supports IR remote, panel buttons, Windows PC, serial RS232, and Web page control for flexible management.
Customizable Settings: Allows customization of device IP for easy multi-device management and tailored output resolution.
Plug-and-Play Convenience: Compact, hardware-based design with rugged construction ensures ease of installation and use.
Eco-Friendly and Efficient: Designed for low power consumption and certified with CE, RoHS, and FCC standards for safety and environmental compliance.
Versatile Applications: Ideal for command and dispatch systems, multi-screen surveillance, engineering displays, multimedia conference halls, and game rooms.
3x1 2x1 2x2 Support 4 Screen Division Seamless UHD Video Switch 4k Hdmi Matrix 4x4 video wall controller
BIT-VWC-U1-MD404Ma is a new audio/video processor with splicing matrix and open window roaming launched by bitvisus , the product has a high-definition processing chip and supports 4-way 4K60 input and 4-way 4K60 output. Using HDMI input interface, HDMI output interface. Apply to the command and control system ,multi-screen video surveillance, engineering display applications, multimedia conference halls, game rooms and so on.
Specification
| Product name |
4K60 HDMI Video Wall Controller Matrix Switcher |
| Product features |
1.Support splicing matrix, splicing superposition, splicing 2
curtains seamless switching
2.Support arbitrary division, roaming overlay
3.Support customized device IP, multiple devices convenient management
4.Support customized output resolution
5.Support for audio and video separation |
| Colour depth |
24bit |
| Colour format |
RGB444,YUV444,YUV422 |
| Storage/working temperature |
-10～50ºC/0～50ºC |
| Product Size |
43×26×4.5cm |
| Product weight |
1.7KG |
| Package Size |
54.5×46.5×12cm |
| Package Weight |
3.3KG |
| Support |
ODM,OEM |
| Warranty |
3year |
| Accessories list |
220V power supply×1, IR receiver×1, remote control×1, network cable×1, USB A-B cable×4 |
| Video Bandwidth |
18Gbps |
3x1 2x1 2x2 Support 4 Screen Division Seamless UHD Video Switch 4k Hdmi Matrix 4x4 video wall controller
