4K60 Seamless Switching Video Wall Controller 8-in 9 -out TV Display Controller HDMI Loopback Multi-view Video Controller

Large Image : 4K60 Seamless Switching Video Wall Controller 8-in 9 -out TV Display Controller HDMI Loopback Multi-view Video Controller

Product Details:

Place of Origin:	Guangdong China
Brand Name:	Bitvisus
Certification:	CE、FCC、GB
Model Number:	BIT-VWC-809MV

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	833
Packaging Details:	5.3KG, 54cm32.5cm15.5cm
Delivery Time:	5-8 work days
Payment Terms:	T/T
Supply Ability:	1000

Contact Now

4K60 Seamless Switching Video Wall Controller 8-in 9 -out TV Display Controller HDMI Loopback Multi-view Video Controller

Description

Product Name:	BIT-VWC-809MV	Product Type:	4K60 Multi-sereen Processor
Function:	Multi-sereen Processor	Feature:	Simultaneously Showing 8 Different Screens
Input:	IN1-2:2XHDMI 2.0,2XDP 1.2; IN3-4:2XHDMI 2.0; IN5-8:4XHDMI 1.3	Output:	9XHDMI1.3,1XHDMI2.0
Warranty:	3 Years	Input Resolution:	3840x2160P60
Ouput Resolution:	1920x1080P60,1920x1200P60	Color:	Balck
Highlight:	4K60 video wall controller , HDMI loopback video controller , multi-view display controller

Product Overview

4K60 Multi-sereen processor

⇒Support 8 inputs, including 4-channels 4K60 (2-channels HDM/DP option),4-channels 1080P60, support 9-channels 1080P60 output. Multi-input and multi-output to meet a variety of application requirements;

⇒Supports up to 5760x3240P30 pixel-to-pixel display;
⇒Support 1 channels HDMl local display back; ⇒Support remote control, RS232, network WEB control, you can log in WEB for control on Windows computer, Apple computer, Pad, mobile phone and other devices, easy and flexible to realize the control and selection of input and output of the device;
⇒Supports CEC control functionality, enabling one-click control of CEC-compatible display devices for standby or power-on, simplifying wiring and manual operations;
⇒Supports 3.5mm audio separation; ⇒Support multi-screen display, you can combine a signal into one screen output display, you can also display different contents in multiple screens; ⇒Support seamless switching of` input signals without black screen or flashing screen; ⇒Built-in output signal enhancement to ensure signal stability and clarity during long-distance transmission;
⇒Supports OSD display to view current information, which can be turned on or off;
⇒Adopt imported industrial-grade chip, 28nm process is stable and reliable, with good heat dissipation design and protection measures to ensure stable operation fora long time.
⇒Welcome to contact us to consult about the products required by your project!

Product Specifications


Produduct Name
BIT-VWC-U1-809MV

Input Maximumum PixelClock Frequency
600MHz

Input Interfaface
ININ1-2:2×HDMI 2.0,2×DP 1.2ININ3-4:2×HDMI 2.0ININ5-8:4×HDMI 1.3

Input Resolution
ININ1-4:3840×2160P60ININ5-8:1920×1080P60

Color depth
8bit

Input color format
RGB444,YUV444,YUV422,YUV420

Outptput Interfaface
9×HDMI 1.3,1×HDMI 2.0

Outptput Maximumum PixelClock Frequency
154MHz

Outptput resolution
1920x1080@60Hz/1920x1200@60Hz

Audio
3.5MM Audio Split

Power supply
12V5A

Power Consumption
40W

Storage/OperatingTemperature
-10～50ºC/0～50ºC

Produduct Dimensions
L×W×H:483mm×200mm×60mm

Shell material
Alliron,all aluminium options

Produduct Weight
2.8KG

Accessory List
1×12V5A power adapapter, 1×Phoenix termrminal, 1×Bluenetwork rk cabable, 1×IR infrfrared head, 1×Remote control

After-saleswarranty
After-sales service 3-year warranty


Features at a Glance


Company Profile

FAQ
Why Choose Bitvisus ?
1.We have our own warehouse, which can ensure us of shipping out orders within 48 hours after payment(weekends and holidays excluded).
2. OEM/ODM offered for our customers.
3.We have various pruduct that may suit for you, such as Video Wall controller, Multiscreen Expander, Multiviewer, Embeded Projector Fusion and so on, which proves that our company has sufficient R&D experience and product quality assurrance.
Shipment & payment
1.T/T, Visa, PayPal, Western Union, L/C available.
2.DHL, UPS, EMS, FedEx, Air freight, Sea freight supported.
How to order?
1. Please send us an email or chat with us via TM, WHATS UP, SKYPE and let us know your requirements for order details.
2. We will provide a proforma invoice to you based on your order requirements.
3. Please check the PI, if everything is OK, we will deliver the goods to you as soon as possible after receiving your payment.
