BIT-Dec64-09: Professional 4K60 Decoder & Video Wall Processor - 9 HDMI Outputs for Multi-Screen Display Control

Name: BIT-Dec64-09: Professional 4K60 Decoder & Video Wall Processor - 9 HDMI Outputs for Multi-Screen Display Control
Brand: Shenzhen Bitvisus Technology Limited
SKU: BIT-Dec64-09
Price: 452.31 USD
Availability: InStock

Product Details

Place of Origin: china

Brand Name: Bitvisus

Certification: ce,Fcc

Model Number: BIT-Dec64-09

Payment & Shipping Terms

Minimum Order Quantity: 1pieces

Price: Contact us

Packaging Details: 483mm × 162mm × 60mm

Delivery Time: 3-15

Payment Terms: D/A,D/P,L/C

Supply Ability: 1000pieces

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                    4K60 HDMI decoder, video wall processor 9 outputs, multi-screen display HDMI switcher


Model:	BIT-Dec64-09	Decoding Capacity:	64x D1@30fps Or 16x 1080p@30fps (H.265/H.264)
Output Interfaces:	9x HDMI 1.4, 1x HDMI Loop-Out	Output Resolution:	1920×1080p60, 1920×1200p60
Network Interface:	Gigabit Ethernet	Control Method:	Web Browser
Power Supply:	12V/5A	Power Consumption:	26W
Dimensions:	483mm × 162mm × 60mm	Operating Temperature:	0°C To 70°C

Model:	BIT-Dec64-09
Decoding Capacity:	64x D1@30fps Or 16x 1080p@30fps (H.265/H.264)
Output Interfaces:	9x HDMI 1.4, 1x HDMI Loop-Out
Output Resolution:	1920×1080p60, 1920×1200p60
Network Interface:	Gigabit Ethernet
Control Method:	Web Browser
Power Supply:	12V/5A
Power Consumption:	26W
Dimensions:	483mm × 162mm × 60mm
Operating Temperature:	0°C To 70°C

Product Description

Bitvisus 4K60 Decoding and Splicing Processorl 1080P or 1200P Outputs 1-channel Loop-Through Output Splicing Screen Converter

BIT-Dec64-09 is a IPC decoding and splicing device independently developed by BTSX. It can open windows to display the video of 64-channel IPC. It offers 9-channel 1080P or 1200P HDMI outputs and supports various screen splicing modes with arbitrary combinations. The device can be controlled via a web page. You can perform operations such as IPC video roaming, window splitting and merging on single - screen and multi - screen setups through the web page.These operations are convenient and easy to control. In addition, the product also supports functions such as IPC search, batch IPC import, IPC video web page echo. The BIT-Dec64-09 meets the monitoring needs in different scenarios and is widely used in security monitoring applications.

Bitvisus 4K60 Decoding and Splicing Processorl 1080P or 1200P Outputs 1-channel Loop-Through Output Splicing Screen Converter

✅ 9 HDMI Outputs + 1 HDMI Loop-Out

✅ Supports up to 64x D1@30fps or 16x 1080p@30fps H.265/H.264 decoding

✅ Flexible video wall layouts: horizontal, vertical, grid, and custom combinations

✅ Full hardware FPGA architecture, 28nm process — fast processing, zero latency

✅ Low power consumption, fanless design, stable and reliable

✅ Web-based control — no software installation required, easy to operate

✅ Supports camera batch import/export, scene tour, electronic map, subtitle display, and more

Bitvisus 4K60 Decoding and Splicing Processorl 1080P or 1200P Outputs 1-channel Loop-Through Output Splicing Screen Converter

Technical Specifications

Parameter	Description
Model	BIT-Dec64-09
Decoding Capacity	64x D1@30fps or 16x 1080p@30fps (H.265/H.264)
Output Interfaces	9x HDMI 1.4, 1x HDMI Loop-Out
Output Resolution	1920×1080p60, 1920×1200p60
Network Interface	Gigabit Ethernet
Control Method	Web browser
Power Supply	12V/5A
Power Consumption	26W
Dimensions	483mm × 162mm × 60mm
Operating Temperature	0°C to 70°C

Bitvisus 4K60 Decoding and Splicing Processorl 1080P or 1200P Outputs 1-channel Loop-Through Output Splicing Screen Converter

Core Functions
